2.92F-PCBV-2H Vertical PCB RF Connectors

2.92mm Female Connector for PCB (2 Screw Hole)Vertical PCB RF Connectors.
EZconn provided high frequency and superior performance solderless microwave Radio Frequency precision compression connectors. The frequency reaches to 40GHz. In solderless coax series of installation could provide fast, easy and without damaging printed circuit board (PCB).
Meanwhile, we provide customized service of compression coax connector for customers' application using our simulation technology. Our compression Microwave/RF coaxial connectors have micro strip and strip line for choosing, providing effective solutions in application for mobile communication (4G & 5G), testing and high speed transmission.

Product Consult

Introduction

Introduction

介紹

Frequency range : 0 ~ 40 GHz
VSWR : 1.35

Related Products

關聯產品

2.92mm(K Band) Flexible Microwave Test & Measurement cable

2.92mm(K Band) RF/Microwave coaxial series was designed with highly rugged physical interfaces in mind that would mate with 3.5mm and SMA dimensions. The 2.92mm(K) series use an air dielectric, with increased the performance up to 40 GHz to respond to accordingly to millimeter wave applications. The outer contact ID is 2.92mm, and OD is 4.55 mm. In response to the fifth generation of wireless communications, 2.92 mm(K) series of products are also suitable for millimeter wave product application.

2.4mm Flexible Microwave Test & Measurement cable

2.4mm RF/Microwave coaxial connector series was designed to eliminate the fragility of the SMA and 2.92mm connectors by increasing the outer wall thickness and strengthening the female fingers.

The outer contact ID is 2.4 mm, and OD is 4.7mm. The performance is up to 50 GHz.

1.85mm Flexible Microwave Test & Measurement cable

1.85mm RF/Microwave coaxial connector was designed to go beyond the SMA interface constraints, and as a result is NOT SMA compatible. Instead, maximum performance to the highest possible frequency that the geometry would allow, along with repeatable measurements after hundreds or even thousands of interconnects, were the design goals.

The connector outer conductor ID is 1.85 mm, and OD is 4.7 mm, allowing compatibility, so that the 1.85mm connector mates with the 2.4mm connector and has the same ruggedness. It’s a 50 Ohms connector with performance up to 67 GHz.

ADP-RA2.92M-2.92M RF/Microwave Coaxial Adaptors

2.92 Male to 2.92 Male Right Angle Adaptor, 2.92mm(K Band) RF/Microwave coaxial series was designed with highly rugged physical interfaces in mind that would mate with 3.5mm and SMA dimensions.
The 2.92mm(K) series use an air dielectric, with increased the performance up to 40 GHz to respond to accordingly to millimeter wave applications. The outer contact ID is 2.92mm, and OD is 4.55 mm.
In response to the fifth generation of wireless communications, 2.92 mm(K) series of products are also suitable for millimeter wave product application.

SMPM JACK/JACK ADAPTER

SMPM JACK TO JACK ADAPTER, The SMPM RF/Microwave coaxial connectors are 20% smaller to SMP connectors and have frequency ranges up to 65 GHz. The SMPM connectors were developed to fit for smaller and higher frequency connectors than the SMP.

The SMPM RF coaxial connectors provide two different levels of retention force: Smooth Bore and Full Detent. EZconn's SMPM connectors are compatible with all kinds of SMPM connectors, including Corning Gilbert's GPPO™ products.

The SMPM connectors are "Push-on" designed, easy to mate connectors, especially for PCB used. Applicable for: Broadband, Instrumentation, Routers, Telecom, High-speed Applications, Cable, PC-Board, Surface-Mount Connections.
